Metal Composite Gasket for Transformers
- Details
Product Introduction:
Asbestos Free, Flexible Graphite Composite gasket asbestos Free, Flexible Graphite , inserted with 0.01"metal steel foil for additional structure.
Offers laminated gaskets that are reinforced with wire mesh, carbon steel foil, aluminum foil, SS304,SS316,nickel alloy.
Flexible Graphite, Standard Grades
BD-8105 FLEXIBLE GRAPHITE
A pure flexible, homogeneous graphite laminated sheet with chemical and physical properties similar to non-laminated flexible graphite.
BD-8106 FLEXIBLE GRAPHITE
It is flexible graphite inserted with a 0.002" 304/316 Stainless Steel sheet.It has excellent chemical resistance and a temperature limit of 1600°F
BD-8107 FLEXIBLE GRAPHITE
Flexible graphite inserted with 0.01"carbon steel foil for additional structure.The aluminum insert has a temperature limit of 900°F.
| Size(mm) | Thickness | 1.0，1.2，1.5，2.0，3.0，4.0 （Or produce according to requirements） | |
| Width | 1000*1000、1500*1500 （Or produce according to requirements） | ||
