Details

NMN(6640)is made of two layers of Nomex paper and one layer of PET film,coated with grade H thermal upgraded adhesive.It has high mechanical properties, dielectric and thermal upgrade properties, and low dissipation factor.It can be used as turn and backing insulating material in grade F and grade H transformers,motors and other electrical appliances. The NMN can work for a long time in a 180℃ environment.

Recommended width

910mmand narrower.Tailor-made width is available.

Storage

The product should be stored in dry,clean and well-ventilated warehouse under 30℃. The fire,heat sources and direct sunshine should be avoided.

No.	Property		Unit	Requirements
1	Nominal thickness		mm	0.15	0.17 0.20 0.25 0.30				0.37 0.47 0.52
2	Thickness tolerance		%	±15					±10
3	Nomex paper		mm	0.05							0.08
4	Film nominal thickness		mm	0.05	0.075	0.10	0.125	0.188	0.25	0.35	0.35
5	Tensile strength	MD	N/10mm Width	≥150	≥160	≥170	≥220	≥270	≥330	≥400	≥450
		CD		≥90	≥90	≥105	≥150	≥200	≥300	≥300	≥300
6	Elongation	MD	%	≥15			≥20
		CD		≥20				≥25
7	Breakdown Voltage	No bending	kV	≥7	≥8	≥11	≥14	≥19	≥23 ≥28		≥30
		Bended		≥6	≥7	≥9	≥12	≥15	≥18	≥20	一
8	Bonding strength	Normal	一	No delamination
		180±2℃/10min		No delamination,no bubble,no lesk of glue
Note:The specification can be determined with customers.
