Asbestos-Free Oil Resistant Fiber Paper Gasket for Transformer
- Details
Product Introduction:
This is a fully cured reinforced cellulose fiber / nitrile butadiene gasket material with excellent crush resistance at high flange pressures. This material has superior sealing properties with fuel, oil and water.This material has a short duration maximum temperature limit of 230ºC (455F).Some common applications include automotive, small engine and compressor ,engine and transmission pan, water pump, and environmental sealing.
Features:
Excellent water and oil resistance, excellent sealing performance;
Long service life, wide range of media resistance, and can be processed into any shape;
Affordable price, easy disassembly and cutting.
| Sealpilot NO. | Thickness（mm） | Width（mm） |
| BD-0330 | 0.22、0.25、0.4、0.5、 0.8、1.0、1.2、1.5 Thickness can be customized Production upon request | 1280，1000 Roll / Whole volume |
| BD-3092 | ||
| BD-0670 | 1050*1150 | |
| BD-0792 | 1000*1000 / roll |
Other dimensions and thicknesses are available on request.
SURFACE TREATMENT:Optional graphite or PTFE finish on request.
Optional steel wire mesh or expanded steel insert on request.
